1060 Aluminum Alloy
Alloy: 1060
Temper: O, H12, H14, H16, H18
Thickness: 0.2mm to 100mm
Width: 500mm to 2000mm
Length: 1000mm to 6000mm
Certification: ISO 9001, SGS test report, material certificate (MTC)
BAOHUI STEEL supplies 1060 Aluminum Alloy, a commercial pure aluminum grade containing 99.6% minimum aluminum content. This alloy offers excellent corrosion resistance, high electrical and thermal conductivity, and outstanding formability. While relatively low in strength, 1060 aluminum is valued for its versatility in applications requiring superior corrosion resistance, electrical conductivity, and workability.
Key Features
High Purity
99.6% minimum aluminum content
Excellent Corrosion Resistance
Superior performance in various environments
Outstanding Electrical Conductivity
61% IACS, ideal for electrical applications
Excellent Thermal Conductivity
234 W/(m·K), suitable for heat transfer applications
Superior Formability
Can be easily formed and deep drawn
Good Weldability
All common welding methods can be used
Technical Specifications
|
Parameter |
Specification |
|
Standard |
ASTM B209, GB/T 3880 |
|
Alloy |
1060 |
|
Temper |
O, H12, H14, H16, H18 |
|
Thickness |
0.2mm to 100mm |
|
Width |
500mm to 2000mm |
|
Length |
1000mm to 6000mm |
Chemical Composition (%)
|
Element |
Requirements |
Typical Value |
|
Aluminum (Al) |
≥ 99.60 |
99.65 |
|
Silicon (Si) |
≤ 0.25 |
0.15 |
|
Iron (Fe) |
≤ 0.35 |
0.25 |
|
Copper (Cu) |
≤ 0.05 |
0.03 |
|
Manganese (Mn) |
≤ 0.03 |
0.02 |
|
Magnesium (Mg) |
≤ 0.03 |
0.02 |
|
Zinc (Zn) |
≤ 0.05 |
0.03 |
|
Titanium (Ti) |
≤ 0.03 |
0.02 |
|
Other Elements |
≤ 0.03 |
0.02 |
Mechanical Properties by Temper
|
Temper |
Tensile Strength (MPa) |
Yield Strength (MPa) |
Elongation (%) |
|
O (Annealed) |
65-95 |
25-55 |
25-35 |
|
H12 |
80-110 |
60-90 |
10-20 |
|
H14 |
95-125 |
80-110 |
6-16 |
|
H16 |
110-140 |
95-125 |
4-12 |
|
H18 |
130-160 |
115-145 |
2-8 |
Physical Properties
|
Property |
Value |
|
Density |
2.70 g/cm³ |
|
Melting Point |
645-655°C |
|
Electrical Conductivity |
61% IACS |
|
Thermal Conductivity |
234 W/(m·K) |
|
Coefficient of Thermal Expansion |
23.6 × 10⁻⁶/°C |
Applications
Chemical Equipment
Storage tanks, processing vessels, piping
Electrical Industry
Busbars, capacitor shells, cable sheathing
Food Processing
Storage containers, processing equipment
Architectural
Decorative panels, roofing, wall cladding
Heat Exchangers
Radiators, cooling fins, heat sinks
Reflectors
Lighting fixtures, solar concentrators
Quality Commitment of 1060 Aluminum Alloy
Certified Quality Assurance
EN 10204 3.1 material certificates
Full chemical composition verification
Mechanical properties testing reports
Third-party inspection support available
Performance Guarantee
Strict dimensional tolerance control
Surface quality inspection
Proper packaging for optimal protection
Consistent batch-to-batch quality
FAQ
Q: What are the main advantages of 1060 aluminum?
A: 1060 offers excellent corrosion resistance, high electrical and thermal conductivity, and superior formability, making it ideal for chemical, electrical, and forming applications.
Q: How does 1060 compare to 1050 aluminum?
A: 1060 has slightly higher purity (99.6% vs 99.5%) and better electrical conductivity, but the differences are minimal for most applications.
Q: Can 1060 aluminum be used for welding?
A: Yes, 1060 has excellent weldability and can be welded using TIG, MIG, and other common welding methods.
Q: What is the maximum service temperature?
A: Continuous service up to 150°C. Not recommended for applications above 200°C.
Q: Is 1060 aluminum suitable for anodizing?
A: Yes, 1060 anodizes very well and is often used for decorative applications requiring anodized finishes.
Request Pricing & Technical Information
Contact Our1060 Aluminum Alloy Experts Today!
For Immediate Quotation, Please Provide:
Product Form and Dimensions
Quantity Requirements
